Jet engine cutaway and exploded assembly

A 3D jet engine explainer pairs an aircraft-mounted cutaway with labeled internal components, cyan and gold flow paths, close-up stage views, and a separated assembly from fan to exhaust.

@techartist_Video · October 2026
How it was made

Claude Opus 5.5 · Three.js

Source and credit

X · Oct 2, 2026 · 1.7k likes · 352k views · 71 comments

Made with AI, according to the source

Discovery collection

Look notesby Reference

A stylized jet engine is shown in cutaway, revealing internal stages from intake through compressor and combustion to exhaust.

Color
Cream, lavender, and deep blue surfaces with teal airflow accents and warm orange highlights.
Type
Technical 3D illustration with small, dark component labels and explanatory captions.
Framing
Side-on engine views emphasize the long horizontal airflow path and exposed internal machinery.
Structure
The engine appears in progressively more detailed cross-sections, with component callouts and concise explanatory text.
